West Red Lake Gold’s Austin 904 Results & the Evidence Behind Madsen De-Risking

• Austin 904 adds a potential new high-grade mining area below Austin, but inclusion in the mine design and production timing is still a pending milestone.
• West Red Lake Gold Mines entered commercial production in early 2026, after management applied a stability test longer than the standard 30-day trigger to confirm operating consistency before declaring the milestone.
• Reconciliation between mined stopes and the updated resource model is tracking well, supported by tight underground drill spacing and a defined lag from drilling to mine-plan inclusion.
• The operating model depends on blending multiple mine complexes, as grade variability remains part of the deposit, even as deeper areas below roughly 600 to 800 metres appear to contain more intact, higher-grade material.
• Monthly cash generation reduces near-term financing pressure, but sustained throughput and conversion of drilling into mineable inventory remain the key tests through 2026.

Austin 904 Complex Drill Results and Madsen Ramp-up

West Red Lake Gold reported strong drill results from the Austin 904 Complex, including 219.73 grams per tonne of gold (g/t Au) over 4.75 metres, including 1,016.57 g/t Au over 1 metre; 148.36 g/t Au over 3 metres, including 222.26 g/t Au over 2 metres; and 133.13 g/t Au over 2.5 metres, including 155.66 g/t Au over 1.3 metres. All holes were drilled from stations on the 13 Level at approximately 650 metres depth. The highest-grade intercept contained visible gold running sub-parallel to foliation and was associated with quartz veining and strong silicification.

Madsen Mine entered commercial production in early 2026, after achieving sustained throughput at roughly 60% to 65% of design capacity over about two months. President and Chief Executive Officer of West Red Lake Gold, Shane Williams, said commercial production was based on consistency and stability rather than a single strong month:

"So usually it's between whatever the throughput is of the project or the mine or the operation, it's around that 60% to 70% consistency over a probably two-month period. You can't go one month and then say, ‘Hey, we're in commercial production,’ and then drop down the last month. That sustained ramp up or that consistency plus over a period of time, that’s 60% to 65% of production."

With a design throughput of approximately 800 tonnes per day, the operation exceeded 600 tonnes per day in November and December 2025, supporting the declaration of commercial production. Management is targeting 800 tonnes per day by the end of the first quarter of 2026 and a steady run rate in the second quarter. During commissioning, the company processed lower-grade material before moving into higher-grade ore from the 4447 area of South Austin. A peak day in December processed approximately 8 to 9 g/t Au from a single stope, providing early evidence of the grade profile expected as mining advances.

Drilling Density & Mine Plan Sequencing

At Madsen Mine, management describes tight underground drilling, interpretation, mine design, and mine-plan inclusion as the core risk-reduction sequence. It takes about 5 to 6 months to move from drilling an area to completing design and placing it into the mine plan, and about 6 to 8 months of lead time to stay ahead of production. That means work completed in the second half of 2025 supports output in the first half of 2026, while drilling underway now is intended to support the back half of 2026 and early 2027.

Williams said mine-plan confidence depends on executing that sequence consistently, not on drill results alone:

"If we go underground, we drill to that tight spacing that is six to seven meters. We take our time well ahead of mining and development, and then we translate that through the design into the mining."

Management says stopes mined to date are reconciling with the updated resource model, which it attributes to dense underground drilling completed ahead of mining. It suggests the operating process is working as intended across the Austin and South Austin areas mined during ramp-up. Austin 904 remains part of the 2026 drill program and is being advanced toward mine design rather than treated as part of the current mine plan.

Austin 904 & Future Mining Inventory

Management draws a direct comparison between Austin 904 and the 4447 area in South Austin. Drilling in 2025 positioned the 4447 area in South Austin to contribute significantly to the 2026 mine plan, following the same sequence now being applied at Austin 904. That parallel matters because it is based on operating precedent from the same mine, not on a stand-alone geological extrapolation.

Most of the Austin 904 panel, as currently defined at approximately 200 by 200 metres, has seen very little historical mining, leaving the main mineralised zone largely intact. This could allow for larger stopes and more efficient development and extraction from the high-grade area. That potential remains unproven, and the 2026 definition program will determine whether the geology supports it.

Grade Profile & Inventory Flexibility

West Red Lake plans to operate three or four mine complexes concurrently, blending higher-grade pockets with lower-grade material to deliver a stable, consistent mill feed. That structure gives the operation flexibility to manage grade variation at the mill head without depending on a single zone to carry production at any given time.

The average grade of the Madsen deposit sits at approximately 5 g/t Au, with quarterly pockets of 6 to 8 g/t Au available in higher-grade zones. Management confirmed that grade variability is a live operating reality rather than a resolved issue. The December 2025 mill head grade of just under 5 g/t Au reflects this profile. That divergence between average grade and higher-grade pockets is precisely why the multi-complex blending model exists.

Below approximately 600 to 800 metres, there is progressively less remnant mining from prior operators and more intact higher-grade material. Earlier operators primarily worked through the upper part of the mine without reaching significant depth, leaving deeper zones largely undisturbed. Austin 904, drilled from the 13 Level at approximately 650 metres depth, lies within the depth range described as increasingly intact and higher grade.

Cash Generation & Residual Financing Risk

West Red Lake Gold reports that the Madsen operation is generating monthly cash flow and is officially in free cash flow. Over the past year, the operation poured 20,000 ounces and generated approximately US$73 million in cash flow. Additionally, the company has built up a cash reserve of $45 to $46 million.

Williams is equally direct about what reaching production means for near-term financing risk:

"We don't expect any more need for cash now. It's self-generating."

Approximately 2,500 ounces per month is sufficient to cover operating costs at Madsen at current gold prices. That figure compares with the prior operator, Pure Gold, which required approximately 4,000 ounces per month to break even. The lower break-even threshold reflects the current higher gold price environment, enhancing the operation's economic flexibility.

Monthly cash generation does not eliminate the execution risk of sustaining 800 tonnes per day throughput, converting Austin 904 from a drill target to a contributing mine, or maintaining grade consistency across multiple concurrent complexes. These uncertainties remain open through 2026, and cash flow will depend on actual throughput and grade performance rather than on the declaration of commercial production alone.

What 904 Changes & What Still Needs Proof

Austin 904 improves the de-risking case at Madsen, but it does not close it. The zone has now delivered high-grade intercepts from below Austin, and management has linked it to the same drill-to-design sequence that moved South Austin into the 2026 mine plan. This positions Austin 904 as a contributor to future mine inventory, extending beyond pure exploration potential.

Madsen now has a broader operating evidence base than it had a year ago, including commercial production, reported reconciliation against the updated resource model, and monthly cash generation. This suggests that the operating process is becoming more predictable.

What remains unproven is whether Austin 904 can convert from a high-grade drill result into scheduled mine inventory on time. The zone is not yet in the mine plan, true thickness has not been formally calculated, and early 2027 production remains a target rather than a committed outcome. The broader test for the rest of 2026 is whether the mine can sustain 800 tonnes per day and maintain grade consistency across multiple concurrent complexes.

The Investment Thesis for West Red Lake Gold Mines

• Austin 904 now links exploration success to possible future mine-plan inventory, with the February drill results tied to 2026 definition drilling and the goal of bringing the zone into consideration for mine design and potential early 2027 production.
• Commercial production followed achievement of the internal throughput threshold and a longer operating-stability period before the milestone was declared.
• Reconciliation against the updated resource model provides a meaningful de-risking signal, supported by tight underground drill spacing and a defined drill-to-design pathway.
• The production plan is built around blending multiple mine complexes, limiting reliance on any single high-grade lens and supporting more consistent mill feed.
• Financing risk also appears lower than in earlier ramp-up stages, with monthly cash generation, reported free cash flow, and an operating-cost threshold of roughly 2,500 ounces per month at current gold prices.

The operating evidence base has improved materially since ramp-up began. The key investment question is whether this progress can deliver sustained throughput, consistent grade, and full mine-plan conversion through the rest of 2026.

TL;DR

West Red Lake Gold has moved Madsen into commercial production and is showing early evidence that its updated operating model is working. Austin 904 adds a potential new high-grade mining area below Austin, but mine-plan inclusion and early 2027 production still depend on continued 2026 drilling, design work, and operating delivery. The key operational milestones through 2026 are sustained 800 tonnes per day throughput, continued reconciliation against the model, and consistent blended grade across multiple mine complexes.
